Split-Type POS
12.1" POS System
1024*768 LED Display
Excellent product quality
Low noise design with laptop power supply
Long-term stable operation
Ergonomic Design
Ultrathin mirror design, generous and fashion
Free to combine, space saving
Keyboard input, high efficiency
Innovative modular design
Easy and quick maintenance
ProcessorIntel Celeron Processor 1037U 1.8Ghz
System Memory2 GB DDR3 (1 x 204-pin DDR3)
Storage Device60G SSD
Power Supply60W (12V/5A) External Power Adaptor
Housing ColorDark Gray
OS SupportWindows XP, POSReady 2009, Windows 7, POSReady 7, Windows 8.1
Display & Touch
LCD12.1" TFT LCD (LED Backlight)
Resolution1024 x 768
I/O Ports
Serial Port3 x External: COM1 (RJ-11), COM2 , COM3(DB9)
Printer Port1 x Bi-directional Parallel Port
USB Port5 x External (4 Rear + 1 Front)
Keyboard 1 x PS/2
LAN Port1 x RJ45 100M LAN
Audio Port1 x Line Out
Video Port1 x VGA
TF Card Slot1 x TF
Mini-PCIe SlotN/A
DC Output1 x 12V DC Jack 2.5 mm
Built-in Device
Built-in PrinterN/A
Built-in MSRPA-MSR23 (Optional)
Built-in RFID ReaderN/A
Built-in WIFIN/A
Built-in KeyboardN/A
Physical Dimensions
Dimensions (WxHxD)370 x 360 x 222 mm
Carton Dimensions (WxHxD)450 x 480 x 310 mm
Weight7.1kg (Net), 9.1kg (Gross)
Integrated 2nd DisplayN/A
Customer DisplayCD-V10E
Receipt PrinterRP3A (with 24V adaptor)
POS KeyboardKB-66MA (Programmable Mechnical Keyboard)
Cash DrawerCR-400B (3-position Lock)
